Camera

Image Sensor: 1/2.8″ Progressive Scan CMOS

Min. Illumination Color: 0.005 Lux @ (F1.2, AGC ON), 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Speed: 1/3 s to 1/100,000 s

Slow Shutter: Yes

Auto-Iris: No

Day & Night: IR Cut Filter

Digital Noise Reduction: 3D DNR

WDR: 120 dB

Angle Adjustment Pan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°



---



Lens

Focal length: 2.0/2.8/4/6/8 mm fixed lens

Aperture: F1.6

FOV:

2.0 mm @ F1.6, horizontal FOV 132°, vertical FOV 77°, diagonal FOV 153°

2.8 mm @ F1.6, horizontal FOV 110°, vertical FOV 60°, diagonal FOV 130°

4 mm @ F1.6, horizontal FOV 82°, vertical FOV 45°, diagonal FOV 98°

6 mm @ F1.6, horizontal FOV 56°, vertical FOV 31°, diagonal FOV 65°

8 mm @ F1.6, horizontal FOV 40°, vertical FOV 22°, diagonal FOV 46°

Lens Mount: M12



---



IR

IR Range: up to 30 m

Wavelength: 850 nm



---



Compression Standard

Video Compression

Main stream: H.265/H.264

Sub-stream: H.265/H.264/MJPEG

Third stream: H.265/H.264

H.264 Type: Main Profile/High Profile

H.264+ Main stream support. H.265 Type Main Profile

H.265+ Main stream support.

Video Bit Rate: 32 Kbps to 16 Mbps

Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM

Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)



---



Smart Feature-set

Behavior Analysis: Line crossing detection, intrusion detection, unattended baggage detection, object removal detection

Exception Detection: No

Face Detection: Yes

Region of Interest: 1 fixed region for main stream and sub stream



---




Max. Resolution 1920 × 1080

Main Stream: H.265/H.264

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub Stream: H.265/H.264/MJPEG

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Third Stream: H.265/H.264

50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)

60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)

Image Enhancement: BLC, 3D DNR

Image Setting: Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser

Target Cropping: No

SVC: H.264 and H.265 encoding

Day/Night Switch Day/Night/Auto/Schedule/Triggered by Alarm In (-S)

Picture Overlay: No



---



Network

Network Storage: Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR

Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour

General Function: One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter

Firmware Version: V5.5.4

API: ONVIF (PROFILE S, PROFILE G), ISAPI

Simultaneous Live View: Up to 6 channels

User/Host: Up to 32 users 3 levels: Administrator, Operator and User

Client: iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect

Web Browser: IE8+, Chrome31.0-44, Firefox30.0-51, Safari8.0+



---



Interface

Audio (-S) 1 input (line in), 1 output (line out), mono

Alarm (-S) 1 input, 1 output (up to 12VDC, 30mA)

Communication Interface: 1 RJ45 10M/100M Ethernet port

On-board storage: Built-in micro SD/SDHC/SDXC slot, up to 128 GB

Reset Button: Yes



---



Audio (-S)

Environment Noise Filtering: Yes

Audio Sampling Rate: 8kHz/16kHz/32kHz/44.1kHz/48kHz



---



General

Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)

Power Supply: -I, -IS: 12 VDC ± 25%, 5.5 mm coaxial power plug, -IM: 12 VDC ± 25%, Molex plug for DC input PoE (802.3af, class 3)

Power Consumption and Current: 12 V DC ± 25%, 0.5 A, max. 6 W PoE: (802.3af,36V-57V), 0.2A to 0.13A, Max:7.5W

Protection Level: IP67, IK08

Material: Metal

Dimensions Camera: Φ 110 mm × 57.4 mm (4.3″ × 2.3″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) With package: 60 mm × 100 mm × 250 mm (2.4″ × 4.0″ × 9.8″)

Weight Camera:

Approx. 580 g (1.3 lb.)

With package: 860 g (1.9 lb)
